DETECTO’s new solo® eye-level clinical scale is the most economical, high-quality digital physician scale with height rod available. The solo® scale features 550 lb x 0.2 lb / 250 kg x 0.1 kg capacity, 14 in W x 15 in D x 2.4 in H low-profile platform, inline mechanical height rod, eye-level weight display and column, one-inch-high LCD readouts, Body Mass Index calculation, integral wheels for mobility, one RS232 serial port, and convenient audible beep confirmation. The solo® is powered by 6 AA batteries, which are included, or an optional AC adapter.
The solo® indicator features 8 simple buttons that are easily identifiable in any language. The scale’s RS-232 serial port allows you to output measurement data to EMR/EHR software. Simply step on the scale to weigh and the scroll arrows let you rapidly enter your height to factor BMI. The mechanical height rod is situated to the side of the LCD, so it never interferes with viewing measurements. The oversized 14 x 15 inch platform with rubber mat is only 2.4 inches high making it easy for patients to step on and off. The AC port is located in the base, so no pesky wires dangle from up on the indicator (AC Adapter optional: model PD-AC).Two integral wheels allow for ease of movement whenever you need to transport the solo®. If you have any questions please give us a call (800)355-2956.
Specifications:
- Model: solo
- Capacity: 550 lb x 0.2 lb / 250 kg x 0.1 kg
- Platform Size: 14 in W x 15 in D x 2.4 in H / 36 cm W x 38 cm D x 6 cm H
- Weight Units: Pounds or Kilograms (selectable upon initialization at start-up; changeable through Settings menu)
- Power: Six (6) AA size Alkaline batteries (included) OR an optional medical device 9V AC/DC wall plug-in adapter (Detecto part number PD-AC).
- Display: Five-digit, seven-segment, 1.0-inch (25-mm) high LCD digits
- Operation Temperature: 50 to 104 ºF / +10 to +40 ºC
- Function Keys: ON/OFF, PRINT, ENTER, UP ARROW, DOWN ARROW, BMI HEIGHT, LOCK/RELEASE, ZERO
- Annunciators: ZERO, LOCK, STA, HOLD, LB, KG, CM, FT/IN, HEIGHT, WEIGHT, BMI, AM, PM
- Scale Dimensions: 14.3 in W x 19.5 in D x 52.0 in H / 36.3 cm W x 49.5 cm D x 132.1 cm H
- Interface: RS-232 Serial Port, 9-Pin (DB-9), Baud Rate 9600
- Height Rod: Mechanical included standard, inline
- Height Rod Units: Inches or Centimeters
- Height Rod Range: 30 in to 84.5 in / 76 cm to 214.5 cm
- Manual Input Height: 2 ft 0.0 in – 7 ft 10.5 in by 0.5 in / 60.0 cm - 240.0 cm by 1cm
- Minimum Weighing: 11 lb / 5 kg
- Wheels: (2) wheels for ease of movement
- Selectable Auto Shut-Off: Up to 9 Minutes
- Construction: Column and height rod – aluminum alloy white powder coated; indicator enclosure, height rod arm, platform and base – white ABS; mat – black PVC
- Product Weight: 17.7 lb / 7.7 kg
- Shipping Weight: 25 lb / 11.3 kg
- Package Dimensions: 30 in W x 20 in D x 11 in H / 76 cm W x 51 cm D x 28 cm H
- UPC Code: 809161197709
The solo® indicator features 8 simple buttons that are easily identifiable in any language. The scale’s RS-232 serial port allows you to output measurement data to EMR/EHR software. Simply step on the scale to weigh and the scroll arrows let you rapidly enter your height to factor BMI. The mechanical height rod is situated to the side of the LCD, so it never interferes with viewing measurements. The oversized 14 x 15 inch platform with rubber mat is only 2.4 inches high making it easy for patients to step on and off. The AC port is located in the base, so no pesky wires dangle from up on the indicator (AC Adapter optional: model PD-AC).Two integral wheels allow for ease of movement whenever you need to transport the solo®. If you have any questions please give us a call (800)355-2956.
Specifications:
- Model: solo
- Capacity: 550 lb x 0.2 lb / 250 kg x 0.1 kg
- Platform Size: 14 in W x 15 in D x 2.4 in H / 36 cm W x 38 cm D x 6 cm H
- Weight Units: Pounds or Kilograms (selectable upon initialization at start-up; changeable through Settings menu)
- Power: Six (6) AA size Alkaline batteries (included) OR an optional medical device 9V AC/DC wall plug-in adapter (Detecto part number PD-AC).
- Display: Five-digit, seven-segment, 1.0-inch (25-mm) high LCD digits
- Operation Temperature: 50 to 104 ºF / +10 to +40 ºC
- Function Keys: ON/OFF, PRINT, ENTER, UP ARROW, DOWN ARROW, BMI HEIGHT, LOCK/RELEASE, ZERO
- Annunciators: ZERO, LOCK, STA, HOLD, LB, KG, CM, FT/IN, HEIGHT, WEIGHT, BMI, AM, PM
- Scale Dimensions: 14.3 in W x 19.5 in D x 52.0 in H / 36.3 cm W x 49.5 cm D x 132.1 cm H
- Interface: RS-232 Serial Port, 9-Pin (DB-9), Baud Rate 9600
- Height Rod: Mechanical included standard, inline
- Height Rod Units: Inches or Centimeters
- Height Rod Range: 30 in to 84.5 in / 76 cm to 214.5 cm
- Manual Input Height: 2 ft 0.0 in – 7 ft 10.5 in by 0.5 in / 60.0 cm - 240.0 cm by 1cm
- Minimum Weighing: 11 lb / 5 kg
- Wheels: (2) wheels for ease of movement
- Selectable Auto Shut-Off: Up to 9 Minutes
- Construction: Column and height rod – aluminum alloy white powder coated; indicator enclosure, height rod arm, platform and base – white ABS; mat – black PVC
- Product Weight: 17.7 lb / 7.7 kg
- Shipping Weight: 25 lb / 11.3 kg
- Package Dimensions: 30 in W x 20 in D x 11 in H / 76 cm W x 51 cm D x 28 cm H
- UPC Code: 809161197709
